$23,245.98

SKU14881
Building Type2-Car Garage with LT
Building Length40
Building Width36
Building Height12
Roof Pitch4/12
Square Feet1440
Truss Type4/12 Pitch 4' o/c
Truss Spacing:4ft on center
Post Type:3-ply GluLam & 6x6 Treated
Post Footings:16" Cookie & Sakrete
Purlins:2x4 2ft on center
Girts:2x4 2ft on center
Garage Doors:10x10 ProDoor 6410 R-10 insulated with windows
Entry Doors:2, 9-lite
Windows:4, 36x48 white, single hung vinyl
Roofing:Everlast Omni 28 Ga.
Siding:Everlast Omni 28 Ga.
Vapor Barrier:Therma Guard
Smart Build Link:Open in 3D Builder

Please Note:

  • This is a materials package only. Construction labor is not included. New Holland Supply can arrange for a contractor to construct your building or you may arrange construction yourself.
  • Our building specifications (snow load, wind rating, etc.) meet local requirements in southeast Pennsylvania. Please notify us if your building materials package needs to be modified to meet local requirements in your area.
  • The finished building(s) shown in the photo gallery may include optional upgrades.
  • Our fulfillment team will contact you before delivery to confirm your order's final details (colors, specs, local sales tax, delivery date, etc.).
  • Please note that our products are subject to lead times, which can extend up to 3-4 weeks.
  • Shipping and tax are calculated at final purchase with sales team.

Pay a deposit $6,973.79

SKU: 14881 Category:

Kit Description:

Material for 36’x40’x12’ pole barn: 3-ply 2×6 glu-lam posts 8’ on/center. (1) 5×16 precast concrete footer block & (1) 80 lb bag sakrete per post. 2-ply 2×12 YP truss bearers. Pre-fabricated trusses with 4/12 roof pitch, 40-5-5 loading, 48″ on center. 12” overhangs on eaves and gables with vented aluminum soffit and painted steel fascia. 2×8 treated skirtboard. 2×4 purlins & girts 24” on/center. Everlast 28 Ga. OMNI Series metal roof & siding. Therma Guard R-9 vapor barrier on roof. Vented closures under ridge cap, foam closure strips at eaves. Painted steel ridge cap, rake & corner trim, base angle, gutter apron, overhead door trim, double angle at gables. (2) ProDoor 6410 10’x10′ overhead door, R-6.8 insulated, vinyl back, raised panel wood grain, white, torsion springs, standard track, weather stripping, steel angle, slide lock, one row windows. (2) 3.0 x 6.8 9-lite, fiberglass entry door with black, keyed entry door knob. (4) 36”x48” white, vinyl, single hung windows. 4” GRK structural screws for headers, color matched screws for roofing and siding. 10’x40’ Open Lean To on eave; 6×6 treated posts 10’ on/center with 5×12 footer blocks and sakrete, 2×10 YP headers & ledger, 2/12 pitch 2×8 rafters 4’ on/center, 2×6 treated Y-braces, 2×4 treated uplift blocks,
