26×36 Garage Kit

$15,038.00

SKU9746
Building Height10.66
Building Length36
Building TypeGarage
Building Width26
Roof Pitch3/12
Square Feet936
Truss TypeStandard Trusses
Location17557
Truss Spacing:4ft on center
Post Type:6x6 Treated
Post Footings:16" Cookie & Sakrete
Purlins:2x4 2ft on center
Girts:2x4 2ft on center
Garage Doors:(1) 16x9 ProDoor 6410 R-10 insulated
Entry Doors:1
Windows:(4) 36x48
Roofing:Everlast Lynx 28 Ga
Siding:Everlast Lynx 28 Ga
Vapor Barrier:Therma Guard
Kit Notes:

Carriage style lights, gutters, and stone wainscot are NOT included in material package price.

Smart Build Link:Open in 3D Builder

Please Note:

  • This is a materials package only. Construction labor is not included. New Holland Supply can arrange for a contractor to construct your building or you may arrange construction yourself.
  • Our building specifications (snow load, wind rating, etc.) meet local requirements in southeast Pennsylvania. Please notify us if your building materials package needs to be modified to meet local requirements in your area.
  • The finished building(s) shown in the photo gallery may include optional upgrades.
  • Our fulfillment team will contact you before delivery to confirm your order's final details (colors, specs, local sales tax, delivery date, etc.).
  • Please note that our products are subject to lead times, which can extend up to 3-4 weeks.
  • Shipping and tax are calculated at final purchase with sales team.

Pay a deposit $4,511.40

SKU: 9746 Category:

Kit Description:

Material for 26’x36’x10’ 8″ pole barn: 6×6 Treated posts 8’ on/center. (1) 5×16 precast concrete footer block & (1) 80 lb. bag Sakrete per post. 2-ply 2×10 SYP headers. Prefabricated trusses with 3/12 roof pitch, 35-5-5 loading, 48″ on center. 12” overhangs on eaves & gables with vented metal soffit and painted steel fascia. 2×8 treated skirtboard. 2×4 purlins & girts 24” on/center. 3’- 4” stone prep wainscot on Front only (stone by others, no stone included). Everlast 28 Ga. LYNX Series metal roof & siding. R-9 Therma-Guard vapor barrier on roof. Vented closures under ridge cap. Foam closures at eave. Painted steel ridge cap, rake & corner trim, base angle, gutter apron, overhead door trim, double angle at gables. (1) 16’x9’ Pro Door 6410 garage door, sandstone, R-10 insulated, standard track, slide lock, dutch corners. (1) 3.0 x 6.8 6 Panel, fiberglass entry door with Black, keyed doorknob, painted in sandstone/clay color. (4) 36”x48” sandstone, vinyl, double hung windows with grids. 4” GRK structural screws for headers. Color matched screws for riding and roofing.
