Kit Description:
Material for 30’x40’x12’ pole barn: 3-ply 2×6 glu-lam posts. (1) 5×16 precast concrete footer block & (1) 80 lb bag sakrete per post. 2-ply 2×10 MSR truss bearers. Pre-fabricated trusses with 4/12 roof pitch, 40-5-5 loading, 48″ on/center. 12” overhangs on eaves and gables with vented aluminum soffit and painted steel fascia. 2×8 treated skirtboard. 2×4 purlins & girts 24” on/center. Everlast 28 Ga. LYNX Series metal roof & siding. Therma Guard R-9 vapor barrier on roof. Vented closures under ridge cap, foam closure strips at eaves. Painted steel ridge cap, rake & corner trim, base angle, gutter apron, overhead door trim, double angle at gables. (2) ProDoor 6410 10’x8′ overhead door, R-610 insulated, metal back, raised panel wood grain, white, torsion springs, standard track, weather stripping, steel angle, slide lock, one row windows, (1) 6.0 x 6.8 double 9-lite, fiberglass entry door with black, keyed entry door knob. (2) 36”x48” white, vinyl, single hung windows. 4” GRK structural screws for headers, color matched screws for roofing and siding.
