30×40 Workshop with Attic & LT Kit

🔍
30x40 workshop with attic & lt kit
30x40 workshop with attic & lt kit
30x40 workshop with attic & lt kit
30x40 workshop with attic & lt kit
30x40 workshop with attic & lt kit
30x40 workshop with attic & lt kit
  1. 30x40 workshop with attic & lt kit
  2. 30x40 workshop with attic & lt kit
  3. 30x40 workshop with attic & lt kit
  4. 30x40 workshop with attic & lt kit
  5. 30x40 workshop with attic & lt kit
  6. 30x40 workshop with attic & lt kit

$32,638.00

SKU14886
Building TypeWorkshop with Attic & LT
Building Length40
Building Width30
Building Height10
Roof Pitch8/12
Square Feet1200
Truss Type8/12 Pitch Attic
Truss Spacing:2ft on center
Post Type:3-ply GluLam & 6x6 Treated
Post Footings:16" Cookie & Sakrete
Purlins:2x4 2ft on center
Girts:2x4 2ft on center
Garage Doors:14x8 ProDoor 6410 R-10 insulated
Entry Doors:1, 9-lite
Windows:9, 36x48 single hung vinyl
Roofing:Everlast Omni 28 Ga.
Siding:1x12 Eastern White Pine Board & Batten
Vapor Barrier:Therma Guard
Smart Build Link:Open in 3D Builder

Please Note:

  • This is a materials package only. Construction labor is not included. New Holland Supply can arrange for a contractor to construct your building or you may arrange construction yourself.
  • Our building specifications (snow load, wind rating, etc.) meet local requirements in southeast Pennsylvania. Please notify us if your building materials package needs to be modified to meet local requirements in your area.
  • The finished building(s) shown in the photo portfolio may include optional upgrades.
  • Our fulfillment team will contact you before delivery to confirm your order's final details (colors, specs, local sales tax, delivery date, etc.).
  • Please note that our products are subject to lead times, which can extend up to 3-4 weeks.
  • Shipping and tax are calculated at final purchase with sales team.

Pay a deposit $9,791.40

SKU: 14886 Category:

Kit Description:

Material for 30’x40’x10’ pole barn W/ Attic and 10′ X 32′ Lean-To: 3-ply 2×6 glu-lam posts 8’ o/c with GreenPost wraps. (1) 5×16 precast concrete footer block & (1) 80 lb bag sakrete per post. 2-ply 2×12 SYP headers. Pre-fabricated attic trusses with 8/12 roof pitch. 30-5-5 loading, 24″ on center, 14’x7’-6” attic room; 3/4” OSB flooring, 7/16” OSB 4’ high on sidewalls, heavy duty pull-down stairs for attic access. 12” overhangs on eaves & gables with vented aluminum soffit and painted, steel fascia. 2×8 treated skirtboard. 2×4 purlins & girts 24” o/c. Everlast 28 Ga. OMNI Series metal roof. Eastern White Pine Board and Batten siding. (1) 14’x8′ Pro Door 6410 garage door, white, steel back, R-10 insulated, standard track, slide lock. (1) 3.0 x 6.8 9-lite, fiberglass entry door. (9) 36”x48” white, vinyl, single hung windows with grids. R-9 Therma-Guard vapor barrier on roof. House wrap on side walls. 10’x32’ Open Lean To on eave; 6×6 treated posts 12’ o/c with 5×12 footer blocks and sakrete, 2×10 YP headers & ledger, 2/12 pitch 2×8 rafters 4’ o/c., 4×6 treated Y-braces, 2×4 treated uplift blocks,
