36×36 Barndominium Kit

🔍
Halterman Chad 4
Halterman Chad 2
IMG 1456
STOCK 36x36x10 Barndo 9764 Job Pack pdf
  1. Halterman Chad 4
  2. Halterman Chad 2
  3. IMG 1456
  4. STOCK 36x36x10 Barndo 9764 Job Pack pdf

$25,123.00

SKU9764
Building Height10
Building Length36
Building TypeBarndominium
Building Width36
Roof Pitch4/12
Square Feet1296
Truss TypeStandard Trusses
Location17557
Truss Spacing:2ft on center
Post Type:3-ply GluLam
Post Footings:16" Cookie & Sakrete
Purlins:2x4 2ft on center
Girts:2x4 2ft on center
Entry Doors:(1) 9-lite & (1) 6.0 double 9-lite
Windows:(13) 36x48 double hung vinyl
Roofing:Everlast Lynx 28 Ga
Siding:Everlast Lynx 28 Ga
Vapor Barrier:Therma Guard
Smart Build Link:Open in 3D Builder

Please Note:

  • This is a materials package only. Construction labor is not included. New Holland Supply can arrange for a contractor to construct your building or you may arrange construction yourself.
  • Our building specifications (snow load, wind rating, etc.) meet local requirements in southeast Pennsylvania. Please notify us if your building materials package needs to be modified to meet local requirements in your area.
  • The finished building(s) shown in the photo gallery may include optional upgrades.
  • Our fulfillment team will contact you before delivery to confirm your order's final details (colors, specs, local sales tax, delivery date, etc.).
  • Please note that our products are subject to lead times, which can extend up to 3-4 weeks.
  • Shipping and tax are calculated at final purchase with sales team.

Pay a deposit $7,536.90

SKU: 9764 Category:

Kit Description:

Material for 36’x36’x10′ pole building: 3-ply-2×6 glue-lam posts.  (1) 5×16 precast concrete footer & (1) 80lb bag sakrete per post. 2-ply 2×12 SYP headers.  Pre-fabricated trusses with 4/12 roof pitch. 30-10-10 loading, 24″ on center. 12” overhangs on eaves & gables with vented aluminum soffit and painted steel fascia. 2×8 treated skirtboard. 2×4 purlins & girts 24″ on/center. Housewrap on walls, ThermaGuard vapor barrier on main roof. Everlast 28 Ga. LYNX series painted steel roofing & siding. Vented closures under ridge cap, foam closure strips at eaves. Painted steel ridge cap, rake & corner trim, base angle, gutter apron, overhead door trim, double angle at gables. (1) 6.0×6.8 double 15-lite fiberglass entry door. (1) 3.0×6.8 6-Panel, solid, fiberglass entry doors. (13) 36”x48” double hung vinyl windows.

8’x72’x8’ Wrap-Around, Open Lean To: Treated 4×6 posts, Treated 2×4 uplift blocks. (1) 5×12 precast concrete footer & (1) 80lb bag sakrete per post. 2×10 SYP headers and ledgers on LT. 2/12 pitch 2×8 rafters 4’ o/c on LT. Painted steel fascia to cover face of porch beam.





I have spoken with a dozen or more building suppliers and this is the most helpful information I have gotten from anyone. Thank you, I greatly appreciate you.

Kyle
